| Min. Order: | 1 Piece/Pieces |
|---|
Key Properties:
| Nanocrystalline | Mn-Zn ferrite | |
Initial Permeability @ 100KHz µr' | 20°C | 16000 | 5300 |
100°C | 16300 | 7000 | |
Imppeadance permeability @ 100KHz µr' | 20°C | 25700 | 5300 |
100°C | 26300 | 7000 | |
Saturation magnetic flux density Bs* (T) | 20°C | 1.35 | 0.44 |
100°C | 1.3 | 0.27 | |
Residual magnetic flux density Br* (T) | 20°C | 0.81 | 0.1 |
100°C | 0.73 | 0.06 | |
Corrective Force Hc* (A/m) | 20°C | 1.3 | 8 |
100°C | 1.4 | 4.9 | |
Curie Temperature Tc (°C) | 570 | 150 | |
Saturation magnetstriction λs(x10-6) | +2.3 | -1.1 | |
Electrical resistivity ρ (µΩcm) | 1.1 | 10x106 | |
Density d(kg/m3) | 7.4x103 | 4.85x103 | |
* DC magnetic properties @ 800A/m | |||
Main Application:· EMC filters· Home Application· Switched -mode power supplies (SMPS), Power supplies· Solar inverters· Uninterruptable power supplies (UPS)· Welding equipment· Wind generators· Frequency converters
Customised size is acceptable, our Common Standard for your first reference as below:
We can design & produce goods based on specifications & drawing, specification needed including:1. Bare core size, Size finished2. Al requirement @ different frequency Our Partner:Top Supplier for Value Customers:
Manufacture:
Certificates:
Safe Package:
Addr :No.1 JiShan BuXia Lu,TianHe District, Guangzhou City, ChinaProduct Categories : Common mode choke
